| Warranty |
The 20-Year, 120 MPH Edge Systems One Wind Warranty is available on orders to meet a project's specification. It provides a maximum of 20 years, 120 MPH coverage for the repair or replacement of any portion of the roof edge system that has failed due to a defect in Metal-Era supplied materials.
|
| Testing |
- Tested per ANSI/SPRI/FM 4435/ES-1 Standard to comply with the International Building Code.
- Factory Mutual approved for wind uplift protection.
- Miami-Dade Approved (No. 23-0912.08 12/11/28) to comply with the “High Velocity Hurricane Zone of the Florida Building Code.”
|
| Standard Sizes |
Sizes range from 3 ½" up to 12 ¼" face heights to accommodate multiple nailers and coverage requirements.- 3 ½"
- 4 ¾"
- 6 ¼"
- 7 ¾"
- 9 ¼"
- 10 ¾"
- 12 ¼"
|
| Accessories |
Factory fabricated accessories provide a cleaner, more aesthetically pleasing appearance. This eliminates the need for field fabrication, providing time and labor savings.
|
| Also Included |
All splice plates and fasteners are included and will arrive to the job site with the product.
|
| Available Materials |
Its unique design allows for covers to be manufactured in 22 ga and 24 ga steel, .040" and .050" aluminum.
|
| Colors |
Choose among a wide range of standard colors and finishes that meet your job requirements. A 30-Year Kynar 500® Finish Warranty is included on coil-coated standard colors. Custom post-coated Kynar 500® colors are available with an included 10-Year Kynar 500® Finish Warranty or a 20-Year Kynar 500® Finish Warranty is available upon request.
Anodized finishes are also available and come with a 5-year warranty (no warranty available for coil anodized finishing; Post-coat/Class 1 Batch Anodized is available with a 5-year warranty with an option to increase to a 10-year warranty for an upcharge). Please email Technical Services regarding pricing for Anodized finishes.
Please note: Express colors available in shorter lead times for 24 ga., .040” and .050” only. Standard lead times, which may be longer, apply for 22 ga. and .063”.
|
| Competitively Priced |
Receive factory-engineered quality, economically priced for cost conscious projects.
|
| Concealed Splice Plates |
Its 4" wide concealed splice plates allow for thermal movement of materials and provides a watertight seal at all joints.
|
| Custom Capabilities |
Radius and specially fabricated products are available to meet the unique needs of each project.
|
| Efficient Design |
Provided in 12'-0" lengths with pre-punched holes for quicker installation and lower labor costs. The fastening holes are slotted to allow for thermal movement of the materials and ensure correct fastener placement and spacing.
|
